Questions for the 1Z0-599 were updated on : Oct 04 ,2024
You deploy more than one application to the same WebLogic container. The security is set on JavaEE
level and all deployed JavaEE applications use the same security roles.
What is your recommendation for an architecture with those requirement
B
Explanation:
Note:
* Types of Security Roles: Global Roles and Scoped Roles
There are two types of security roles in WebLogic Server:
/ A global security role can be used in any security policy. Oracle provides several default global roles
that you can use out of the box to secure your WebLogic resource
/ A scoped role can be used only in policies that are defined for a specific instance of a WebLogic
resource (such as a method on an EJB or a branch of a JNDI tree). You might never need to use
scoped roles. They are provided for their flexibility and are an extra feature for advanced customers.
Incorrect:
Not E: Role mapping is the process whereby principals (users or groups) are dynamically mapped to
security roles at runtime. In WebLogic Server, a Role Mapping provider determines what security
roles apply to the principals stored a subject when the subject is attempting to perform an operation
on a WebLogic resource. Because this operation usually involves gaining access to the WebLogic
resource, Role Mapping providers are typically used with Authorization providers.
When your WebLogic Server solution needs to be scaled out with additional capacity and you dont
want to add additional hardware, which three techniques should you us?
B, D, E
A highly available WebLogic cluster in UNIX is configured for automatic server migration. Node
Managed is configured on both machines to start managed servers.
How should you simulate a managed server failure to test whether automatic server migration is
working?
A
Explanation:
Note:
* It is recommended that you shutdown WebLogic Server instances through the Administration
Console.
* If automatic server migration is enabled, the servers are required to contact the cluster leader and
renew their leases periodically. Servers will shut themselves down if they are unable to renew their
leases. The failed servers will then be automatically migrated to the machines in the majority
partition.
A customer claims that while redeploying a web application in the production system all their
customers are having to log in again. What do you recommend?
D
Explanation:
Restrictions on Production Redeployment Updates
WebLogic Server can host a maximum of two different versions of an application at one time.
Note:
* When you redeploy a new version of an application, you cannot change:
An application's deployment targets
An application's security model
A Web application's persistent store settings
To change any of the above features, you must first undeploy the active version of the application.
Incorrect:
* (not A)
Production redeployment enables you to update and redeploy an application in a production
environment without stopping the application or otherwise interrupting the application's availability
to clients. Production redeployment saves you the trouble of scheduling application downtime,
setting up redundant servers to host new application versions, manually managing client access to
multiple application versions, and manually retiring older versions of an application.
* (not C) Not dependant on whether the application is JRockit or Hotspot.
* (not E)
The production redeployment strategy is supported for:
Standalone Web Application (WAR) modules and enterprise applications (EARs) whose clients access
the application via a Web application (HTTP).
Enterprise applications that are accessed by inbound JMS messages from a global JMS destination, or
from inbound JCA requests.
All types of Web Services, including conversational and reliable Web Services, but not 8.x Web
Services.
Production redeployment is not supported for:
Standalone EJB or RAR modules. If you attempt to use production redeployment with such modules,
WebLogic Server rejects the redeployment request. To redeploy such modules, remove their version
identifiers and explicitly redeploy the modules.
Applications that use JTS drivers. For more information on JDBC application module limitations, see
JDBC Application Module Limitations in Configuring and Managing JDBC Data Sources for Oracle
WebLogic Server.
Applications that obtain JDBC data sources via the DriverManager API; in order to use production
redeployment, an application must instead use JNDI to look up data sources.
Applications that include EJB 1.1 container-managed persistence (CMP) EJBs. To use production
redeployment with applications that include CMP EJBs, use EJB 2.x CMP instead of EJB 1.1 CMP.
Reference: Reference; Deploying Applications to Oracle WebLogic Server 12c, Redeploying
Applications in a Production Environment
A common approach to solve application performance issues is to add more hardware. Which two
reasons describe why this alone does not always solve performance problems?
A,C
A customer has a critical, performance-sensitive web application that connects to a multinode Oracle
RAC database. Which feature of WebLogic can provide significant performance benefit?
A
Explanation:
Reference: Oracle WebLogic Server Active GridLink for Oracle Real Application Clusters(RAC)
A customer needs to implement a Highly Available solution for JMS that has a primary data center
and a backup. Which three steps would you perform when designing your solution?
A, C, E
Explanation:
Note:
Which WebLogic optimization allows one non-XA resource to participate in a distributed transaction?
B
Explanation:
http://my-java-planet.blogspot.com/2014/04/which-weblogic-optimization-allows-one.html
A customer has a Stock Watch application that publishes stock recommendations to different
customers and programs. The stock recommendation message should be processed by only one of
the JMS Servers in the cluster. Which JMS model should be used?
A
Explanation:
JMS queue
A staging area that contains messages that have been sent and are waiting to be read. Note that,
contrary to what the namequeuesuggests, messages don't have to be delivered in the order sent. A
JMS queue only guarantees that each message is processed only once.
Incorrect:
Not B: (Only one queue required)
* A distributed destination is a set of destinations (queues or topics) that are accessible as a single,
logical destination to a client. A distributed destination has the following characteristics:
It is referenced by its own JNDI name.
Members of the set are usually distributed across multiple servers within a cluster, with each
destination member belonging to a separate JMS server.
* A distributed queue is a set of physical JMS queue members. As such, a distributed queue can be
used to create aQueueSender,QueueReceiver, and aQueueBrowser. The fact that a distributed
queue represents multiple physical queues is mostly transparent to your application.
Not Topic:
JMS topic
A distribution mechanism for publishing messages that are delivered to multiple subscribers.
A customer has a critical, performance-sensitive web application that connects to a multimode
Oracle RAC database. Which feature of WebLogic can provide signification benefit?
C
Explanation:
Active GridLink for Oracle RAC
In Oracle WebLogic Server 10.3.4, a single data source implementation has been introduced to
support an Oracle RAC cluster. It responds to FAN events to provide Fast Connection Failover (FCF),
Runtime Connection Load-Balancing (RCLB), and RAC instance graceful shutdown. XA affinity is
supported at the global transaction Id level. The new feature is called WebLogic Active GridLink for
RAC; which is implemented as the GridLink data source within WebLogic Server.
Note:
* The WebLogic Server JDBC subsystem has supported Oracle RAC since WLS version 9.0, originally
developed for Oracle9i RAC. This support is based on a particular type of data source configuration,
called a multi data source. A multi data source is a data source abstraction over one or more
individual data sources. It serves JDBC connections from each of the member data sources according
to a specified policy. A RAC multi data source configuration requires that each member data source
obtain connections to a particular RAC instance.
Reference: How-To: Use Oracle WebLogic Server with a JDBC GridLink Data Source
A customer needs to ensure that the number of threads servicing an application does not exceed the
number of database connections available to the application.
What step must you take to address this situation?
B
Explanation:
To manage work in your applications, you define one or more of the following Work Manager
components:
Fair Share Request Class:
Response Time Request Class:
Min Threads Constraint:
Max Threads Constraint:
Capacity Constraint
Context Request Class:
Note:
* max-threads-constraintThis constraint limits the number of concurrent threads executing
requests from the constrained work set. The default is unlimited. For example, consider a constraint
defined with maximum threads of 10 and shared by 3 entry points. The scheduling logic ensures that
not more than 10 threads are executing requests from the three entry points combined.
A max-threads-constraint can be defined in terms of a the availability of resource that requests
depend upon, such as a connection pool.
A max-threads-constraint might, but does not necessarily, prevent a request class from taking its fair
share of threads or meeting its response time goal. Once the constraint is reached the server does
not schedule requests of this type until the number of concurrent executions falls below the limit.
The server then schedules work based on the fair share or response time goal.
* WebLogic Server prioritizes work and allocates threads based on an execution model that takes
into account administrator-defined parameters and actual run-time performance and throughput.
Administrators can configure a set of scheduling guidelines and associate them with one or more
applications, or with particular application components.
* WebLogic Server uses a single thread pool, in which all types of work are executed. WebLogic
Server prioritizes work based on rules you define, and run-time metrics, including the actual time it
takes to execute a request and the rate at which requests are entering and leaving the pool.
The common thread pool changes its size automatically to maximize throughput. The queue
monitors throughput over time and based on history, determines whether to adjust the thread
count. For example, if historical throughput statistics indicate that a higher thread count increased
throughput, WebLogic increases the thread count. Similarly, if statistics indicate that fewer threads
did not reduce throughput, WebLogic decreases the thread count. This new strategy makes it easier
for administrators to allocate processing resources and manage performance, avoiding the effort and
complexity involved in configuring, monitoring, and tuning custom executes queues.
Reference: Using Work Managers to Optimize Scheduled Work
What are the three steps you should take to tune a JDBC Connection pool in WebLogic from the
initial settings in a production environment?
A, C, E
Explanation:
A:
* Troubleshooting Slow Response Time from the Client and Low Database Usage
These symptoms are usually caused by a bottleneck upstream of the database, perhaps in the JDBC
connectionpooling. Monitor the active JDBC connections in the WebLogic Console and watch for
excessive waiters and wait times; increase the pool size, if necessary.
* Attribute: Maximum Capacity
Maximum number of physical database connections that this connection pool can contain. Different
JDBC Drivers and database servers may limit the number of possible physical connections.
C: Attribute: Statement Cache Size
The algorithm used to maintain the statement cache:
LRU - After the statementCacheSize is met, the Least Recently Used statement is removed when a
new statement is used.
Fixed - The first statementCacheSize number of statements is stored and stay fixed in the cache. No
new statements are cached unless the cache is manually cleared.
E: If the queue appears starved but adding execute threads does not improve performance,
there may be resource contention. Because CPU utilization is low, the threads are probably
spending much of their time waiting for some resource, quite often a database connection.
Use the JDBC monitoring facilities in the console to check for high levels of waiters or long
wait times. Adding connections to the JDBC connection pool may be all that is required to
fix the problem.
Note:
* If you had a JDBC connection pool where the Initial Capacity and Maximum Capacity attributes
were different, you might want to create a gauge monitor to monitor the maximum and minimum
number of connections.
By setting the Threshold Low value to be one less than the Initial Capacity, your gauge monitor
trapcould monitor the ActiveConnectionsCurrentCount attribute of the JDBCDataSourceRuntime
MBean and alert you whenever the number of active connections are less than the Initial Capacity
(which might indicate database connectivity problems).
You have a durable subscriber, and the subscriber is down or not reachable when the message is
produced. Which two options regarding the expiry of these messages are true?
B, D
Explanation:
By default, JMS messages never expire. When applications send messages to queues or topics with
durable subscribers, WebLogic must retain the message until it is consumed. This is fine in most
point-to-point messaging applications because consumers are constantly consuming messages. Any
message sent to a queue will typically be consumed in a relatively short period of time. If the
consumers get disconnected, they will usually reconnect as soon as possible and start processing any
messages that might have built up in the queue.
D: For durable subscribers to a topic, this is not necessarily true. The messaging system is forced to
retain any message that has not been consumed by a durable subscriber, regardless of whether that
durable subscriber will ever return. In this case, WebLogic is at the mercy of the durable subscriber
to unsubscribe when it no longer wishes to receive the messages. If the durable subscriber logic is
flawed in such a way that the subscribers do not unsubscribe properly, the messaging system will
start to fill up with messages that may never be delivered. This calls for real caution in using durable
subscribers. Fortunately, there is another way to help deal with this problem. Message expiration can
be set at the connection factory level. Using a connection factorys default time-to-live attribute, we
can specify the number of milliseconds that WebLogic should retain an undelivered message after it
is sent.
Identify the two options that can be used to patch WebLogic Server without Incurring application
downtime.
C, D
Explanation:
Note:
* Rolling Upgrade is the process of upgrading a running WebLogic Server cluster with a patch,
maintenance pack, or minor release without shutting down the entire cluster or domain. During the
rolling upgrade of a cluster, each server in the cluster is individually upgraded and restarted while the
other servers in the cluster continue to host your application.
WebLogic 12c, the Maven plug-in has been enhanced with which Maven goal?
D
Explanation:
wls-maven-pluginDelivered in WebLogic Server 12c, provides enhanced
functionality to install, start and stop servers, create domains, execute WLST
scripts, and compile and deploy applications.
Reference: Developing Applications for Oracle WebLogic Server, Using the WebLogic Development
Maven Plug-In
